感應器(Sensors)

CMOS sensor

取像速度(Scanning Speed)

1/15 sec

影像解析度(Image  Resolution)

500 dpi (H),500 dpi(V)

Platen Size

20 x 21mm(H * V)

影像擷取尺寸(Image Size )

264 * 324 pixel (H * V) / 360*400pixel (H * V)

灰度(Gray Level)

8bit/pixel, 256 Gray

圖像長寬比(Image Ration of Length To

Width)

1 : 1

介面(Interface)

USB 2.0 Hi-Speed

電力(Power)

1W,(Via USBport )( 200mA,stand by:60mA)

尺寸(Dimension)

100 mm (L) x 60 mm(M) x 50 mm(H)

操作環境(Operating Temperature)

0°C~50°C

濕度(Operating Humidity)

90% RH or less,

noncondensing

Operating Systems Supported

Windows 10/ 8 / 7 /XP

Image Capture Speed

0.2 ~ 0.4seconds

(varies according to finger condition)

對比速度(Verification  Speed)

< 0.1 sec

100,000. matching per sec (StartekńsBioServer)

錯誤接受率(FAR)

1/100,000

錯誤拒絕率(FRR)

1/100

靜電放電(ESD)

15KV

認證標章

CE, FCC
